Installation
14
Note:
Please use PV connector crimper to pinch the point of the arrow.
Step 2
Step 3
Note:
You’ll hear click sound when the connector assembly is correct.
Note:
Set battery type and manufacturer, please refer to Chapter 5.3.
BMS(Battery Management System)communication is needed
between inverter and battery.
MC
MC
!
AF-TH series hybrid inverters are compatible with lithium battery. For lead acid
battery or batteries with other brands, please confirm with local distributor or
Afore for technical support.
