Installation
15
Step 2
Step 3
Step 1
Note:
Battery cable suggestion Cross - section 6-8 AWG
Please make sure the battery polarities are correct.
Battery cable
19±1mm
Pass the crimped battery harness through the waterproof connector and the cover.
Insert the wire harness into the terminals according to “+” and “-” polarity, make the
insulated terminals parallel with the terminals , the crimping screw torque is 2.0±0.1N.m
