Afore AF3K-THP - Page 19

Step 4
Use an open-end wrench to tighten the waterproof lock.
A “click” sound will be heard when the connector assembly is correct.
Step 5
Insert the battery connector into the inverter, if hear a “click”, it means the battery
connection is finished.
Step 6
Installation
16
