Afore AF5000W-LE - Page 10

Step 1
Place the base against the wall, the distance between the base and the wall is
30mm as followed.
Step 2
Screw the locating pin into the base and put the first battery pack on the base.
4 . 3 Installation
（2.1） （2.2）
（2.3） （2.4）
Note: Levelness of the base is less than 2mm.
15 16
X X X X
