Afore HNS1000TL-1 Installation And Operation Manual

2.Safety & Symbols
2.1 Safety Precautions
1. All work on the inverter must be carried out by qualified electricians.
2. The device may only be operated with PV generators.
Safety & Symbols
02
Type
Single-Phase(One MPPT Tracker)
HNS1000TL-1
HNS1500TL-1
HNS2000TL-1
HNS2500TL-1
HNS3000TL-1
HNS3600TL-1
6
9
12
13
15
16
16
16
20
20
25
25
Max AC Current [A] Rated current of AC breaker[A]
Circuit Breaker and Surge Protector Recommendation:
SPD: Lightning protection system, refer to the following options:
AC side, nominal discharge current 20KA, second grade lightning protection,
protection voltage 2.5KV
DC side, nominal discharge current 20KA, second grade lightning protection,
protection voltage 3.2KV
The wiring distance between the inverter and the distribution box should be at
least 5 meters.
Utility: Referred to as “grid” in this manual, i.e. the media your electric power
company provides power to your place. Please note that Inverter can only be
connected to low-voltage systems (namely, 220/230Vac, 50/60Hz).
Single-Phase(Two MPPT Trackers)
HNS3000TL
HNS3600TL
HNS4000TL
HNS5000TL
15
16
20
23
25
25
32
32

Afore HNS1000TL-1 Specifications

General

Brand	Afore
Model	HNS1000TL-1
Category	Inverter
Language	English
