©Copyright LOTRONIC 2016 BEAM2R-X Page 6
6- LAMP
6.1 LAMP DESCRIPTION
LAMP MODEL POWER OF LAMP
LIFE/HOUR COLOR TEMPERATURE
WARNING!
There is a safety hazard or damage if install similar bulb to reduce the risk of damage to light,
do change the lamp before using time over 90% of lamp life .
6.2 LAMP REPLACE
Attention! When replace the lamp is forbidden to touch lamp with bare hand,
to avoid the greasy dirt stains filament. Filament must be kept clean
1. Disconnect the power. Before replace lamp, fixture need 20 minutes for lamp cooling. Fasten the
head with Y axis protect lock in 60 ° position.
2. Use cross screwdriver to open the light body cover, remove the fan bracket, as this picture show:
3. Please loose the connect wire as the following.
