©Copyright Lotronic 2018 Manual DMX512-PRO 12
- MOVEMENT SPEED: The running speed can be adjusted between 1 and 100 %.
- DELAY LEVEL: The delay time for the operation with several devices can be adjusted
between 0 and 30 seconds.
Fig. 7.3 Adjusting parameters
• Color effects 10-16: The running speed can be adjusted between 1 and 100 %
(indication “MOVEMENT SPEED“).
Memorizing Illumination Scenes
32 memory banks are available for illumination scenes. Each scene contains the
values of all control channels including the pan and tilt settings of the connected light
effect units as well as movement patterns or color effects at the time of storage.
Fig. 7.4 Programming mode
1. Call the programming mode. For this, keep the REC pressed until the LED above
the button lights.
2. Press the button FIXTURE.
• The control LED lights.
3. Use the number buttons 1-16 to select the devices to be controlled.
• The corresponding LEDs of the buttons light.
• If a number button is pressed once again, the corresponding device is deselected.
Fig. 7.5 Adjusting DMX values
4. Adjust the desired DMX values (0-255) for the DMX channels using the sliding
controls and, if necessary, the pan and tilt wheels.
• As soon as a fader is moved, the display indicates the number of the control channel
in the lower line and the current output value as a DMX value.
5. If necessary, movement patterns or color effects can be integrated in the scene.
For this, call the effect mode with the button MOVEMENTS and select the desired
effect with the number buttons 1-16. Exit the effect mode again by pressing the
button FIXTURE.
6. If necessary, use the button PAGE to switch between the two channel groups 1-16
(LED A lights) and 17-32 (LED B lights) and repeat steps 3 and 5, until the desired
values are assigned to all channels.
7. Deselect the adjusted devices with the corresponding number button 1-16.
8. Repeat the steps 3 to 5 for all further devices to be adjusted.
SPEED:42%
PROGRAM
CH:02 Val:098
