Ag Leader Technology PF3000 User Manual

PF3000 Cotton Yield Monitor
General
Ag Leader Technology
March 2002
1
-
6
When some display items (like swath) are selected, an up and down arrow
symbol will appear on the right of the display line. This indicates you can
change the setting of the item with the UP or DOWN ARROW keys. After
you have made the change you must press the key to the right of the display
line to deselect the line.
Menu Key
The MENU key switches the menus on the bottom of the display. There are
two main menus that you can view by pressing the MENU key. They are
shown below.
It is recommended to display the FIELD, LOAD, menu during normal
operation of the monitor, unless you are marking and therefore need to
display marks on the bottom.
Main Menus:
FIELD LOAD SHOW MAP MARKS
SUMMARY CAL SETUP DIAG
Menu Selection
Keys
The name above the four menu selection keys on the bottom of the display
will change depending on what you are doing on the monitor.
The bottom RIGHT and LEFT ARROW keys are used to view additional
menu or display items. If you see a right and left arrow symbol on the
display above the bottom RIGHT and LEFT ARROW keys, this indicates
you can press the bottom RIGHT and LEFT ARROW keys to view more
menu or display items. Refer to Figure 2.
