Ag Leader Technology PF3000 User Manual

PF3000 Cotton Yield Monitor
Ag Leader Technology
Calibrating Stop Height
March 2002
3
-
17
Introduction
The stop height is the height at which the head must be raised at the end of a
pass to shut off area counting. The stop height number is a reference
number for the monitor to determine the height of the head. It does not
pertain to feet or inches of height.
The stop height number must be set.
You must have the monitor installed in the picker to set the stop height.
Stop Height
Calibration
To view the stop height calibration screen press the:
Screen
MENU key
CAL key
STOP HEIGHT key
Calibration

Ag Leader Technology PF3000 Specifications

General

Brand	Ag Leader Technology
Model	PF3000
Category	Monitor
Language	English
