PF3000 Cotton Yield Monitor

Calibrating Stop Height

Ag Leader Technology

March 2002

Step Action

1 Use the UP or DOWN ARROW keys to select stop height setting.

2 Press the SET HEIGHT key.

Step Action

3 Move the picker head to the height at which you want the monitor to

stop counting area.

4 Press the SET HEIGHT key. The monitor will automatically set the

stop height setting equal to the current stop height. Press the

ACCEPT key.

5 Press the EXIT key twice to return to the main operating screen.

NOTE: You can manually adjust the stop height number by pressing the

UP or DOWN ARROW key when the screen above is displayed. Adjustment

of the sensor maybe needed to gain more range of motion. Adjust the point

at which the chain attaches to the threaded rod and/or adjust the location

that the chain is attached to the head.

* * *
