2.3 THE ELECTRICAL ENCLOSURE
The electrical enclosure for the AG Maxi is bolted to the underside of the chassis, located
above the battery. The enclosure protects wiring components inside of the enclosure from
water, muck, and bedding. Here you will find components for conveyor, agitator and
charging circuits. Protruding from the enclosure are 3x push button reset trips for the
conveyor, agitator and charging circuit.
2.3.1 CIRCUIT BREAKERS
1) Conveyor circuit breaker
2) Agitator circuit breaker
3) Charging circuit breaker
