Splitting the Tractor
02-10 79024230 A Rev.
FIG. 28: Disconnect hydraulic hose (1) which connects
the orbit roll power steering unit with the oil cooler.
FIG. 29: Disconnect power steering hoses at the
cylinder side. Release hoses from clamps.
Disconnect the brake rods.
FIG. 30: Remove the snap ring (1), spring pin and
springs then remove the brake pedal (2).
FIG. 31: Remove the snap ring (1) and slide the PTO
lever (2) outside.
FIG. 28
i-9778
1
FIG. 29
i-9779
FIG. 30
2
1
i-9781
FIG. 31
1
2
i-9782
