Splitting the Tractor
FIG. 32: Remove the neutral switch (1).
Remove front mount fixing bolts (LH and RH).
Remove rear mount fixing bolts (LH and RH).
FIG. 33: Lift up the frame set gradually making sure that
all related wirings, pipes and links are disconnected.
FIG. 32
1
i-9783
FIG. 33
i-9784
