79026547 Rev. A 02-9
Engine Component Removal and Installation
ALTERNATOR - REMOVAL AND
INSTALLATION
Removal Procedure
m
WARNING: Hot engine components can
cause injury from burns. Before performing
maintenance on the engine, allow the
engine and the components to cool.
FIG. 12: Battery disconnect switch.
IMPORTANT: Park the tractor on a hard, level surface.
Location of battery disconnect switch (1).
FIG. 13: Disconnect battery at battery disconnect switch.
Rotate and remove key(1) to disconnect the battery
power.
FIG. 12
1
N012206001
FIG. 13
1
N012206002
