4450A EN 20060221Advanced operation (‘Key-operator mode’)
CR 85-X DIGITIZER
To clear an image plate jam:
1 Remove the cassette.
Refer to ‘Clearing cassette jams’ on page 45.
2 Check whether the image plate is jammed in the pre-scan or in the post-scan unit.
Refer to the diagram above.
• If the image plate is jammed in the pre-scan unit, continue with step 3.
• If the image plate is jammed in the post-scan unit, continue with step 4.
Status Action
1
Plate jam in the post-scan unit. Image is
OK.
Erase the image plate.
2
Plate jam in the pre-scan unit. Image
plate is not erased but cassette status is
set to ‘erased’.
1 Re-identify cassette via ID Station.
2 Digitize cassette.
3
Plate jam in the scanner. Cassette status is
set to ‘erased’. Image is damaged.
1 Erase the image plate.
2 Redo the patient exam.
