1
3
2
1.
Cassette insertion marker, pointing towards the digitizer
2.
Label indicating tube side of the cassette
3.
Cassette orientation marker, indicates image orientation at image
processing software.
AGFA CR Plates and Cassettes | Using the Agfa CR Plates and Cassettes | 23
2492F EN 20180417 1049
