DX- D 600
User Manual
0242F EN 20181218
143
8.4.2 ERROR LIST
Following tables list all defined error codes:
 Error Code.
 User Error Message. Displayed error message.
 Error Description: Explains the error and reasons.
 Action: Suggests the action to be completed in order to correct the error.
These errors are divided into nine different categories:
1 System/Miscellaneous 0 to 11099
2 Ceiling Suspension Motor Controller Boards 11100 to 11 199
3 RAD Wall Stand Motor Controller Boards 11200 to 11299
4 RAD Table Motor Controller Boards 11300 to 11399
5 Positioning 11500 to 11599
6 Safety Messages and Tomography 11600 to 11699
7 Auto-position ing 11700 to 1 1799
8 Auto-centering 11800 to 11899
9 Auto-tracking 11900 to 11999
Table 8-1
System/Miscellaneous
CODE USER ERROR MESSAGE ERROR DESCRIPTIO N ACTION
9 Collimator cause
Click on Collimator Information
to know the reason
10 Interlock cause
Check if Interlock is activated. Click on
Interlock icon to know the reason
11 Collimator Mode
Click on Collimator Information
to know the reason
12 Collimator Error Check SID/aperture relation
13 Stitching Cause T ry again
15 Dosimeter not communicating DAP NOT communicating: Test Contact Service
16 Dosimeter not communicating DAP NOT communicating: Initialization Contact Service
17 Dosimeter not communicating DAP NOT communicating: Heartbeat Contact Service
18 Dosimeter not communicating DAP NOT communicating: Measure Contact Service
19 Collimator not communicating Collimator NOT communicating Contact Service
