Table 8-2
Ceiling Suspension Motor Controller Boards
CODE USER ERROR MESSAGE ERROR DESCRIPTIO N ACTION
11100 Control Board Error: CS-Longitudinal
Motor Controller Board not connected
or I2C communication problems
Check the Motor Controller I/F
Connection
11101 Control Board Error: CS-Transversal
Motor Controller Board not connected
or I2C communication problems
Check the Motor Controller I/F
Connection
11102 Control Board Error: CS-Vertical
Motor Controller Board not connected
or I2C communication problems
Check the Motor Controller I/F
Connection
11103 Control Board Error: CS-Angular
Motor Controller Board not connected
or I2C communication problems
Check the Motor Controller I/F
Connection
11104 Control Board Error: CS-Rotational
Motor Controller Board not connected
or I2C communication problems
Check the Motor Controller I/F
Connection
11105
Invalid Calibration Data:
CS-Longitudinal
Axis not calibrated,
calibration file corrupted
Calibrate once again
If message persists change SBC/CF
11106
Invalid Calibration Data:
CS-Transversal
Axis not calibrated,
calibration file corrupted
Calibrate once again
If message persists change SBC/CF
11107 Invalid Calibration Data: CS-Vertical
Axis not calibrated,
calibration file corrupted
Calibrate once again
If message persists change SBC/CF
11108 Invalid Calibration Data: CS-Angular
Axis not calibrated,
calibration file corrupted
Calibrate once again.
If message persists change SBC/CF
11109 Invalid Calibration Data: CS-Rotational
Axis not calibrated,
calibration file corrupted
Calibrate once again
If message persists change SBC/CF
11110
Operative rejected: CS-Longitudinal
position out of calibrated range:
Right there, only MANUAL
movement allowed
Axis moved out of
defined range manually .
Axis not calibrated.
Potentiometer misaligned.
Potentiometer or Potentiometer
Circuitry defective.
A/D converter problem
Check position feedback
Contact Service
11111 Board failure: CS-Longitudinal
No motor power or
motor/driver defective.
Potentiometer/Tachometer or
circuitry defective.
Coupling did not engage
Change board
11112 End-switch limit: CS-Longitudinal
Axis moved out of
defined range manually .
Axis not calibrated.
Potentiometer misaligned.
Potentiometer or Potentiometer
Circuitry defective.
A/D converter problem
Check End Switch Limit position,
activation, operation.
Check End Switch Limit range
