Page #19 background image
19
General Purpose Cable
Ta bl e 3 GPIO General Purpose Cable (5188-8029) descriptions
Wire Color PIN Enh. Remote
Green 1 IO 1
Violet 2 IO 2
Blue 3 IO 3
Yellow 4 IO 4
Black 5 IO 5
Orange 6 IO 6
Red 7 IO 7
Brown 8 IO 8
Gray 9 1 wire DATA
NC 10 DGND
NC 11 +5 V ERI out
NC 12 PGND
NC 13 PGND
NC 14 +24 V ERI out
White 15 +24 V ERI out
