3rd party (Peak Detection) triggered fraction collection
Figure 4 Connection to 3rd party device for fraction triggering
NOTE
Use any of the following cable options depending on output device:
#063, #064.
For explanations of the option numbers refer to Ta b l e 2 on page 14.
