33120-66521 – Main PC Assembly
Reference Agilent Part Mfr. Mfr. Part
Designator Number Qty Part Description Code Number
C101-C102 0160-6497 78 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C103-C105 0160-5945 26 CAP-FXD 0.01 uF 50 V 04222 08055C103KAT A
C107 0160-5945 CAP-FXD 0.01 uF 50 V 04222 08055C103KAT A
C108 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C109-C110 0160-5945 CAP-FXD 0.01 uF 50 V 04222 08055C103KAT A
C111-C113 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C114-C117 0160-5945 CAP-FXD 0.01 uF 50 V 04222 08055C103KAT A
C201-C202 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C203 0160-5945 CAP-FXD 0.01 uF 50 V 04222 08055C103KAT A
C204 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C205 0160-5945 CAP-FXD 0.01 uF 50 V 04222 08055C103KAT A
C206-C207 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C208-C210 0160-5945 CAP-FXD 0.01 uF 50 V 04222 08055C103KAT A
C211-C213 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C301-C306 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C308-C309 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C310-C312 0160-5945 CAP-FXD 0.01 uF 50 V 04222 08055C103KAT A
C313-C318 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C319 0160-5945 CAP-FXD 0.01 uF 50 V 04222 08055C103KAT A
C320 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C401-C402 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C404 0160-5967 6 CAP-FXD 100 pF 50 V 04222 08051A101JAT A
C405 0160-5962 2 CAP-FXD 15 pF 50 V 04222 08051A150JAT A
C406 0160-5967 CAP-FXD 100 pF 50 V 04222 08051A101JAT A
C407 0160-5962 CAP-FXD 15 pF 50 V 04222 08051A150JAT A
C408 0160-5967 CAP-FXD 100 pF 50 V 04222 08051A101JAT A
C409 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C410 0160-5945 CAP-FXD 0.01 uF 50 V 04222 08055C103KAT A
C411 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C412 0160-5945 CAP-FXD 0.01 uF 50 V 04222 08055C103KAT A
C413-C422 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C423 0160-5959 1 CAP-FXD 33 pF 50 V 04222 08051A330JAT A
C424 0160-5947 4 CAP-FXD 1000 pF 50 V 04222 08055C102KAT A
C425 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C426-C427 0160-6736 2 CAP-FXD 0.01uF +-10% 50 V CER X7R 51406 GRM426X7R103K50
C428 0160-5967 CAP-FXD 100 pF 50 V 04222 08051A101JAT A
C429-C432 0160-6497 CAP-FXD 0.1 uF 25 V 04222 12065C104KAT A
C503-C504 0160-7405 2 CAP-FXD 560 pF +-10% 50 V CER X7R 28480 0160-7405
C505-C506 0160-5953 5 CAP-FXD 270 pF 50 V 02444 08051A271JAT A
C507-C508 0160-5964 3 CAP-FXD 180 pF 50 V 04222 08051A181JATRA
C509-C510 0160-5958 2 CAP-FXD 39 pF 50 V 04222 08051A390JAT A
C521-C522 0160-5954 3 CAP 220 pF 5% 50V 04222 08051A221JAT A
C531-C532 0160-5955 4 CAP-FXD 68 pF 50 V 04222 08051A680JATRA
C533-C534 0160-5976 2 CAP-FXD 12 pF 50 V 04222 08051A120JAT A
7
Chapter 7 Replaceable Parts
33120-66521 – Main PC Assembly
115
