Front-panel menu reference
A: MODulation MENU
1: AM SHAPE Õ 2: AM SOURCE Õ 3: FM SHAPE Õ 4: BURST CNT Õ 5: BURST RATE Õ
Õ 6: BURST PHAS Õ 7: BURST SRC Õ 8: FSK FREQ Õ 9: FSK RATE Õ 10: FSK SRC
1: AM SHAPE Selects the shape of the AM modulating waveform.
2: AM SOURCE Enables or disables the internal AM modulating source.
3: FM SHAPE Selects the shape of the FM modulating waveform.
4: BURST CNT Sets the number of cycles per burst (1 to 50,000 cycles).
5: BURST RATE Sets the burst rate in Hz for an internal burst source.
6: BURST PHAS Sets the starting phase angle of a burst (-360 to +360 degrees).
7: BURST SRQ Selects an internal or external gate source for burst modulation.
8: FSK FREQ Sets the FSK “hop” frequency.
9: FSK RATE Selects the internal FSK rate between the carrier and FSK frequency.
10: FSK SRC Selects an internal or external source for the FSK rate.
B: SWP (Sweep) MENU
1: START F Õ 2: STOP F Õ 3: SWP TIME Õ 4: SWP MODE
1: START F Sets the start frequency in Hz for sweeping.
2: STOP F Sets the stop frequency in Hz for sweeping.
3: SWP TIME Sets the repetition rate in seconds for sweeping.
4: SWP MODE Selects linear or logarithmic sweeping.
C: EDIT MENU *
1: NEW ARB Õ 2: POINTS Õ [3: LINE EDIT] Õ [4: POINT EDIT] Õ [5: INVERT] Õ [6: SAVE AS] Õ 7:DELETE
1: NEW ARB Initiates a new arb waveform or loads the selected arb waveform.
2: POINTS Sets the number of points in a new arb waveform (8 to 16,000 points).
3: LINE EDIT Performs a linear interpolation between two points in the arb waveform.
4: POINT EDIT Edits the individual points of the selected arb waveform.
5: INVERT Inverts the selected arb waveform by changing the sign of each point.
6: SAVE AS Saves the current arb waveform in non-volatile memory.
7: DELETE Deletes the selected arb waveform from non-volatile memory.
* The commands enclosed in square brackets ( [ ] ) are “hidden” until you make a selection from the NEW ARB
command to initiate a new edit session.
