D: SYStem MENU
1: OUT TERM Õ 2: POWER ON Õ 3: ERROR Õ 4: TEST Õ 5: COMMA Õ 6:REVISION
1: OUT TERM Selects the output termination (50
W
or high impedance).
2: POWER ON Enables or disables automatic power-up in power-down state “0”.
3: ERROR Retrieves errors from the error queue (up to 20 errors).
4: TEST Performs a complete self-test.
5: COMMA Enables or disables a comma separator between digits on the display.
6: REVISION Displays the function generator’s firmware revision codes.
E: Input / Output MENU
1: HPIB ADDR Õ 2: INTERFACE Õ 3: BAUD RATE Õ 4: PARITY Õ 5: LANGUAGE
1: HPIB ADDR Sets the GPIB bus address (0 to 30).
2: INTERFACE Selects the GPIB or RS-232 interface.
3: BAUD RATE Selects the baud rate for RS-232 operation.
4: PARITY Selects even, odd, or no parity for RS-232 operation.
5: LANGUAGE Verifies the interface language: SCPI.
F: CALibration MENU *
1: SECURED Õ [1: UNSECURED] Õ [2: CALIBRATE] Õ 3: CAL COUNT Õ 4: MESSAGE
1: SECURED The function generator is secured against calibration; enter code to unsecure.
1: UNSECURED The function generator is unsecured for calibration; enter code to secure.
2: CALIBRATE Performs individual calibrations; must be UNSECURED.
3: CAL COUNT Reads the total number of times the function generator has been calibrated.
4: MESSAGE Reads the calibration string (up to 11 characters) entered from remote.
* The commands enclosed in square brackets ( [ ] ) are “hidden” unless the function generator is UNSECURED for
calibration.
Chapter 3 Front-Panel Menu Operation
Front-panel menu reference
38
