Agilent Technologies 33120A Service Guide

Reference Agilent Part Mfr. Mfr. Part
Designator Number Qty Part Description Code Number
JM1001-1004 0699-1503 7 RESISTOR .05 +-100% TKF 28480 0699-1503
JM1051 0699-1503 RESISTOR .05 +-100% TKF 28480 0699-1503
K501-K502 0490-1664 8 RELAY 2C 5VDC-COIL 1A 110VDC 28480 0490-1664
K601-K602 0490-1664 RELAY 2C 5VDC-COIL 1A 110VDC 28480 0490-1664
K801-K804 0490-1664 RELAY 2C 5VDC-COIL 1A 110VDC 28480 0490-1664
L501-L502 9140-1716 2 INDUCTOR 910 nH +2% -2% 02113 1008CS-911XGBC
L503-L504 9140-1102 8 INDUCTOR 560 nH +-5% 2.8W-MMX3.4LG-MM 24226 03273
L505-L506 9140-1425 2 INDUCTOR SMT 270 nH 5% 24226 SM3-270J
L521-L522 9140-1102 INDUCTOR 560 nH +-5% 2.8W-MMX3.4LG-MM 24226 03273
L531-L532 9140-1103 2 INDUCTOR 680 nH +-5% 2.8W-MMX3.4LG-MM 24226 03273
L533-L534 9140-1102 INDUCTOR 560 nH +-5% 2.8W-MMX3.4LG-MM 24226 03273
L535-L536 9140-1101 2 INDUCTOR 470 nH +-5% 2.8W-MMX3.4LG-MM 24226 03273
L537-L538 9140-1102 INDUCTOR 560 nH +-5% 2.8W-MMX3.4LG-MM 24226 03273
L601-L602 0699-1503 RESISTOR .05 +-100% TKF 28480 0600-1503
L801 9140-1099 1 INDUCTOR SMT 220 nH 5% 09021 KL32TER22J
Q401 1854-1037 4 TRANSISTOR PD=350 MW FT=300 MHZ 04713 MMBT3904
Q601-Q602 1854-1037 TRANSISTOR PD=350 MW FT=300 MHZ 04713 MMBT3904
Q603-Q604 1853-0516 4 TRANSISTOR PD=350 MW FT=600 MHZ 04713 MMBTH81
Q605 1853-0567 2 TRANSISTOR PD=350 MW FT=250 MHZ 04713 MMBT3906
Q701 1854-1148 2 TRANSISTOR PD=350 MW FT=650 MHZ 04713 MMBTH10
Q702 1853-0516 TRANSISTOR PD=350 MW FT=600 MHZ 04713 MMBTH81
Q704 1854-1148 TRANSISTOR PD=350 MW FT=650 MHZ 04713 MMBTH10
Q705 1853-0567 TRANSISTOR PD=350 MW FT=250 MHZ 04713 MMBT3906
Q707 1853-0516 TRANSISTOR PD=350 MW FT=600 MHZ 04713 MMBTH81
Q708 1854-1037 TRANSISTOR PD=350 MW FT=300 MHZ 04713 MMBT3904
Q709 1854-1445 1 TRANSISTOR NPN SI SC-59 28480 1854-1445
Q710 5063-1420 1 TRANSISTOR PNP 600 MHZ 28480 5063-1420
Q711-Q712 1853-0728 3 TRANSISTOR PNP SI TO-261AA (SOT-223) 28480 1853-0728
Q713 1854-0597 1 TRANSISTOR NPN 2N5943 SI TO-39 PD=1W 04713 2N5943
Q714 1853-0728 TRANSISTOR PNP SI TO-261AA (SOT-223) 28480 1853-0728
Q715-Q717 1854-1303 3 TRANSISTOR NPN SI TO-261AA (SOT-223) 28480 1854-1303
Q718 1853-0293 TRANSISTOR P RF TO39 30V 500 MA 1GHZ 04713 2N5583
R101-R104 0699-1318 20 RESISTOR 1K +-1% .125 W TKF TC=0+-100 28480 0699-1318
R106-R109 0699-1423 12 RESISTOR 215 +-1% .125 W TKF TC=0+-100 28480 0699-1423
R110 0699-1386 1 RESISTOR 5.62K +-1% .125 W TKF TC=0+-100 28480 0699-1386
R111-R112 0699-1318 RESISTOR 1K +-1% .125 W TKF TC=0+-100 28480 0699-1318
R114-R116 0699-1391 11 RESISTOR 10K +-1% .125 W TKF TC=0+-100 28480 0699-1391
R117 0699-1423 RESISTOR 215 +-1% .125 W TKF TC=0+-100 28480 0699-1423
R118-R119 0699-1318 RESISTOR 1K +-1% .125 W TKF TC=0+-100 28480 0699-1318
R120-R121 0699-1423 RESISTOR 215 +-1% .125 W TKF TC=0+-100 28480 0699-1423
R201 0699-1318 RESISTOR 1K +-1% .125 W TKF TC=0+-100 28480 0699-1318
R203 0699-1391 RESISTOR 10K +-1% .125 W TKF TC=0+-100 28480 0699-1391
R205 0699-3034 1 RESISTOR 1K +-1% .1W TKF TC=0+-100 2M627 MCR10-FZHM-F-1001
Chapter 7 Replaceable Parts
33120-66521 – Main PC Assembly
118
