Agilent Technologies 33120A Service Guide

Reference Agilent Part Mfr. Mfr. Part
Designator Number Qty Part Description Code Number
R908 0699-1318 RESISTOR 1K +-1% .125 W TKF TC=0+-100 28480 0699-1318
R909 0699-3408 1 RESISTOR 1K +-5% 1 W TKF TC=0+-200 2M627 MCR1001KJ
R910 0699-1391 RESISTOR 10K +-1% .125 W TKF TC=0+-100 28480 0699-1391
R1001 0699-1380 3 RESISTOR 3.16K +-1% .125 W TKF TC=0+-100 28480 0699-1380
R1002 0699-1424 2 RESISTOR 237 +-1% .125 W TKF TC=0+-100 28480 0699-1424
R1003 0699-1380 RESISTOR 3.16K +-1% .125 W TKF TC=0+-100 28480 0699-1380
R1004 0699-1424 RESISTOR 237 +-1% .125 W TKF TC=0+-100 28480 0699-1424
R1008-R1009 0699-1391 RESISTOR 10K +-1% .125 W TKF TC=0+-100 28480 0699-1391
R1010 0699-1421 RESISTOR 178 +-1% .125 W TKF TC=0+-100 28480 0699-1421
R1011 0699-1433 RESISTOR 562 +-1% .125W TKF TC=0+-100 28480 0699-1433
R1012 0699-1391 RESISTOR 10K +-1% .125 W TKF TC=0+-100 28480 0699-1391
R1013 0699-1380 RESISTOR 3.16K +-1% .125 W TKF TC=0+-100 28480 0699-1380
R1014 0699-1384 RESISTOR 4.64K +-1% .125 W TKF TC=0+-100 28480 0699-1384
R1052 0699-1327 1 RESISTOR 1M +-1% .125 W TKF TC=0+-100 28480 0699-1327
RP301-RP302 1810-1360 2 RESISTOR-NETWORK 16PINS,THICK FILM,SMD 28480 1810-1360
RP401 1810-1065 1 NET-RES 15 1.0K OHM 16-PIN 11236 767161102G
RP403-RP404 1810-1331 2 NET-RES 8 220.0 OHM 16-PIN 11236 767163221G
RP601 1810-1159 1 RESISTOR-NETWORK 28480 1810-1159
SHD902 33120-00614 1 RFI SHIELD 28480 33120-00614
SPR1-SPR2 0380-0643 2 STANDOFF-HEX .255-IN-LG 6-32-THD 28480 0380-0643
SPR10-SPR20 2190-0577 2 WASHER- NO. 10 .194-IN-ID .294-IN-OD 20859 03118
U101 1990-1552 3 OPTO-ISOLATOR LED-IC GATE IF=10 MA-MAX 28480 HCPL-2211-300
U102 1821-1479 1 IC-BIT SLICE MPU/MCU 34649 N80C196KB
U103 1820-8907 1 IC GATE-ARY CMOS 27014 SCX6206AK0
U104 33120-88861 1 PROG PAL 28480 33120-88861
U105 1818-4777 1 IC 256K-BIT SRAM 70-NS CMOS 28480 1818-4777
U106 1818-5699 1 IC, CMOS, AMB, 32 PIN, 120 NANOSECONDS 34335 AM29F010-120JC
U107 1820-5808 2 IC FF CMOS/74HC D-TYPE POS-EDGE 04713 MC74HC273DW
U108 1820-5941 1 IC DCDR CMOS/74ACT BIN 8-TO-1-LINE 28480 1820-5941
U109 1820-5944 2 74ACT32-GATE, QUAD 2-INPUT OR 28480 1820-5944
U201 1820-6306 3 IC TRANSCEIVER CMOS/HCT BUS OCTL 27014 MM74HCT245WM
U202 1820-5808 IC FF CMOS/74HC D-TYPE POS-EDGE 04713 MC74HC273DW
U203-U204 1820-6306 3 IC TRANSCEIVER CMOS/HCT BUS OCTL 27014 MM74HCT245WM
U205 1818-5093 1 IC 256K-BIT SRAM 25-NS CMOS 04713 MCM6206DJ25
U206 1821-0976 1 IC MODULATOR ANLG 68 PIN PLCC 01295 F107563FN
U210 1820-7244 2 IC SCHMITT-TRIG CMOS/74AC INV HEX 27014 74AC14SC
U211 1820-5940 1 IC GATE CMOS/74ACT AND QUAD 2-INP 28480 1820-5940
U212 1820-5944 74ACT32-GATE, QUAD 2-INPUT OR 07263 02237
U213 1990-1552 OPTO-ISOLATOR LED-IC GATE IF=10MA-MAX 28480 HCPL-2211-300
U214 1820-8830 2 IC MUXR/DATA-SEL CMOS/ACT 8-TO-1-LINE 04713 MC74ACT251D
U215 1820-5937 1 IC FF CMOS/74AC D-TYPE POS-EDGE-TRIG 07263 02237
U216 1820-4998 1 IC GATE TTL/F OR QUAD 2-INP 27014 74F32SC
U217 1820-5943 2 IC MUXR/DATA-SEL CMOS/74ACT 2-TO-1-LINE 07263 02237
U218 1821-0559 1 IC FF BICMOS/ABT D-TYPE POS-EDGE-TRIG 01295 SN74ABT16374ADL
Chapter 7 Replaceable Parts
33120-66521 – Main PC Assembly
122
