Agilent Technologies 33120A Service Guide

The Agilent Technologies 33120A is a high-performance 15 MHz
synthesized function generator with built-in arbitrary waveform
capability. Its combination of bench-top and system features makes this
function generator a versatile solution for your testing requirements now
and in the future.
Convenient bench-top features
 10 standard waveforms
 Built-in 12-bit 40 MSa/s arbitrary waveform capability
 Easy-to-use knob input
 Highly visible vacuum-fluorescent display
 Instrument state storage
 Portable, ruggedized case with non-skid feet
Flexible system features
 Four downloadable 16,000-point arbitrary waveform memories
 GPIB (IEEE-488) interface and RS-232 interface are standard
 SCPI (Standard Commands for Programmable Instruments) compatibility
 Agilent IntuiLink Arb Waveform Generation Software for
Microsoft
®
Windows
®
Warning
The procedures in this manual are intended for use by qualified,
service-trained personnel only.
Agilent 33120A
15 MHz Function /
Arbitrary Waveform Generator
Note: Unless otherwise indicated, this manual applies to all Serial Numbers.
