Agilent Technologies 33521A User Manual

211
Chapter 3 Features and Functions
Embedded Waveform Editor
3
Clip allows you to specify upper and lower limits on the waveform and
changes voltage values outside those limits to be equal to the limits. In
this example, the waveform was clipped to stay within the -400 mV lower
limit and the 700 mV upper limit.
Image Before Operation
Image After Operation
