Agilent Technologies 4294A Configuration Guide

4
Description Model Number
Requires
(Instrument
must already
include the
following)
Additional Information
Test Leads 16048H None 2 m BNC connector leads. DC – 110 MHz. Usable with the
4294A only
16048H-001 None Adds BNC Bracket
16048H-ABA None U.S. - English localization
16048H-ABJ None Japan – Japanese localization
SMD Test Fixture 16034E None For SMD; (0.1 to 8)L x (0.5 to 10)W x (0.5 to 10)H mm.
DC – 40 MHz. Operation and Service Manual is furnished.
SMD Test Fixture 16034G None For SMD; (0.1 to 5)L x (0.3 to 1.6)W x (0.3 to 1.6)H mm.
DC - 110 MHz. 100 Ω SMD resistors set is furnished.
16034G-ABA None U.S. - English localization
16034G-ABJ None Japan – Japanese localization
SMD Test Fixture 16034H None For Array-type SMD; (0.1 to 5)L x (≤ 15)W x (0.6 to 3)H mm.
DC – 110 MHz. 100 Ω SMD resistors set and Operation
Manual are furnished.
SMD Test Fixture 16044A None Kelvin contact test fi xture for SMD; (1.6 to 8)L x (0.8 to
8)W x (0.8 to 3)H mm. DC – 10 MHz.
16044A-ABA None U.S. – English localization
16044A-ABJ None Japan – Japanese localization
Test Fixture 16047A None For axial or radial lead device. DC – 13 MHz. Operation
and Service Manual is furnished.
16047A-701 None Adds Shorting plate
Test Fixture 16047D None For axial or radial lead device. DC – 40 MHz. Operation
and Service Manual is furnished.
16047D-701 None Adds Shorting plate
Test Fixture 16047E None For axial or radial lead device. DC – 110 MHz.
16047E-ABA None U.S. – English localization
16047E-ABJ None Japan – Japanese localization
Tweezers Test Fixture 16334A None For SMD; ≤ 10 mm L. Tweezers type; cable length 1 m.
DC – 15 MHz. Shorting block and Operation and Service
Manual are furnished.
Kelvin Clip Leads 16089A None 2 large clips. 5 Hz – 100 kHz. Choose mandatory option
16089A-800 or C20. Operation and Service Manual is
furnished.
16089A-800 None Cable length: 1 m (standard)
16089A-C20 None Cable length: 2 m
Kelvin Clip Leads 16089B None 2 medium clips. 5 Hz – 100 kHz. Choose mandatory option
16089B-800 or C20. Operation and Service Manual is
furnished.
16089B-800 None Cable length: 1 m (standard)
16089B-C20 None Cable length: 2 m
Available Accessories – General/Miscellaneous Measurement Accessories – continued
