General Information
FFT
FFT
Points Fixed at 2048 points
Source of FFT Analog channels 1 or 2 (or 3 or 4 for 54624A), 1+2, 1-2, 1*2
Window Rectangular, Flattop, Hanning
Noise Floor -70 to -100 dB depending on averaging
Amplitude Display In dBV
Frequency Resolution: 0.097656/(time per div)
Maximum Frequency 102.4/(time per div)
Storage
Save/Recall (non-volatile) 3 setups and traces can be saved and recalled internally
Floppy Disk
Image formats
Data formats
Trace/setup formats
3.5” 1.44 MB double density
TIF, BMP
X and Y (time/voltage) values in CSV format
Recalled
I/O
RS-232 (serial) standard port 1 port; XON or DTR; 8 data bits; 1 stop bits; parity=none; 9600, 19200, 38400, 57600 baud
rates
Parallel standard port Printer support
Printer Compatibility HP DeskJet, HP LaserJet with HP PCL 3 or greater compatibility
Compatibility– black and white @150x150 dpi
gray scale @ 600x600 dpi
Epson–black and white @180x180 dpi
Seiko–DPU-414 black and white
Optional GPIB Interface Module Fully programmable with IEEE488.2 compliance
Typical GPIB throughput of 20 measurements or twenty 2000-point records per second.
* Denotes Warranted Specifications, all others are typical. Specifications are valid after a 30-minute warm-up period and
±10 °C from firmware calibration temperature.
