3-16
Testing Performance
To verify horizontal Dt and 1/Dt accuracy
4
Change the calibrator to 1-µs markers. Change the time base to
200 ns/div. Adjust the trigger level to obtain a stable display.
5 Measure the following:
Frequency 1 MHz — The test limits are 997.9 kHz to 1.002 MHz.
Period 1 µs — The test limits are 997.9 ns to 1.002 µs.
If the measurements are not within the test limits, see the “Troubleshooting”
chapter. Then return here.
54622A/22D/24A only
6
Change the calibrator to 10-ns markers. Change the time base to
5 ns/div. Adjust the trigger level to obtain a stable display.
7 Measure the following:
Frequency 100 MHz — The test limits are 99.10 MHz to 100.9 MHz.
Period 10 ns — The test limits are 9.91 ns to 10.09 ns.
If the measurements are not within the test limits, see the “Troubleshooting”
chapter. Then return here.
54621A and 54621D
only
8
Change the calibrator to 20 ns markers. Change the time base to 5 ns/div.
Adjust the trigger level to obtain a stable display.
9 Measure the following:
Frequency 50 MHz — The test limits are 49.77 MHz to 50.23 MHz.
Period 20 ns — The test limits are 19.91 ns to 20.09 ns.
If the measurements are not within the test limits, see the “Troubleshooting”
chapter. Then return here.
