Agilent Technologies 54624A Service Guide

6-13
Replacing Assemblies
To remove the power supply
5
Use a flat-blade screwdriver to gently unhook the latch that holds the
white power-actuator shaft to the power switch, then disconnect the
shaft from the power switch. After you disconnect the shaft, make sure
you position it in the recess along the side of the display bracket.
Figure 6-10
Unhooking the power switch shaft
(
Gently apply outward
pressure at this corner
of the slot
service.book Page 13 Wednesday, December 18, 2002 8:35 AM
