6-14
Replacing Assemblies
To remove the power supply
6
Using the T20 TORX driver, remove the screw holding the power supply
board to the deck.
Figure 6-11
Removing the power supply
7 Slide the power supply board toward the front panel about 1/2 inch. Slip
the power supply board keyhole slots off of the pins on the deck.
service.book Page 14 Wednesday, August 28, 2002 3:25 PM
