3-16
Testing Performance
To verify horizontal Dt and 1/Dt accuracy
4
Change the calibrator to 100 ns markers. Change the time base to
20 ns/div. Adjust the trigger level to obtain a stable display.
5 Measure the following:
Frequency 10 MHz — The test limits are 9.98 MHz to 10.02 MHz.
Period 100 ns — The test limits are 99.77 ns to 100.2 ns.
If the measurements are not within the test limits, see the “Troubleshooting”
chapter. Then return here.
54642A/42D only
6
Change the calibrator to 2 ns markers. Change the time base to
1 ns/div. Adjust the trigger level to obtain a stable display.
7 Measure the following:
Frequency 500 MHz — The test limits are 492.6 MHz to 507.6 MHz.
Period 2 ns — The test limits are 1.970 ns to 2.030 ns.
If the measurements are not within the test limits, see the “Troubleshooting”
chapter. Then return here.
54641A and 54641D
only
8
Change the calibrator to 2.857 ns markers. Change the time base to 1
ns/div. Adjust the trigger level to obtain a stable display.
9 Measure the following:
Frequency 350 MHz — The test limits are 346.4 MHz to 353.7 MHz.
Period 2.857 ns — The test limits are 2.827 ns to 2.887 ns.
If the measurements are not within the test limits, see the “Troubleshooting”
chapter. Then return here.
