3-21
Agilent 54641A/41D Performance Test Record
Agilent 54641A/54641D
Serial No. ______________________________________ Test by _____________________________
Test Interval ____________________________________ Work Order No. ______________________
Recommended Next Testing ________________________ Temperature ____________
Threshold Specification Limits Ch D7-D0 Ch D15-D8
Accuracy Test
5 V - 250 mV 4.750 V ________ ________
(100 mV + 3% of
threshold setting)
5 V + 250 mV 5.250 V ________ ________
-5 V - 250 mV -5.250 V ________ ________
-5 V + 250 mV -4.750 V ________ ________
0 V - 100 mV -100 mV ________ ________
0 V + 100 mV 100 mV ________ ________
Voltage Measurement Accuracy
Range Power Supply Setting Test Limits Channel 1 Channel 2
5 V/Div 35 V 34.04 V to 35.96 V ________ ________
2 V/Div 14 V 13.616 V to 14.384 V ________ ________
1 V/Div 7 V 6.808 V to 7.192 V ________ ________
500 mV/Div 3.5 V 3.404 V to 3.596 V ________ ________
200 mV/Div 1.4 V 1.3616 V to 1.4384 V ________ ________
100 mV/Div 700 mV 680.8 mV to 719.2 mV ________ ________
50 mV/Div 350 mV 340.4 mV to 359.6 mV ________ ________
20 mV/Div 140 mV 136.16 mV to 143.84 mV ________ ________
10 mV/Div 70 mV 68.08 mV to 71.92 mV ________ ________
5 mV/Div 35 mV 34.04 mV to 35.96 mV ________ ________
2 mV/Div 14 mV 13.232 mV to 14.768 mV ________ ________
Bandwidth Test Limits Channel 1 Channel 2
3 dB at 350 MHz ________ ________
Horizontal ∆t and 1/∆t Accuracy
Generator Setting Test Limits Results
Frequency 10 kHz 9.98 kHz to 10.02 kHz ________
Period 100
µs 99.79 µs to 100.2 µs ________
Frequency 10 MHz 9.98 MHz to 10.02 MHz ________
Period 100 ns 99.77 ns to 100.2 ns ________
Frequency 350 MHz 346.4 MHz to 353.7 MHz ________
Period 2.857 ns 2.827 ns to 2.887 ns ________
Trigger Sensitivity Test Limits Channel 1 Channel 2
Internal trigger 25 MHz at 1 division ________ ________
350 MHz at 0.6 divisions ________ ________
Ext
External trigger 350 MHz at <200 mV
p-p
________
100 MHz at <100 mV
p-p
________
