Using the Oscilloscope
To select a command from the menu bar
3-33
To select a command from the menu bar
1 Click on a menu bar item.
2 Move the pointer to the desired menu item.
3 Click the mouse button.
The desired command is executed, or a dialog box is presented for you to
configure the oscilloscope.
If you continue to hold the mouse button after step 1, release the button in
step 3 to execute the command.
Some menus have submenus. These are indicated by an arrow at the right side
of the command. When you move the pointer to one of these menu commands,
the submenu automatically appears. You can then move the pointer to the
desired command on that submenu and click the mouse button to execute the
command.
Figure 3-23
Selecting a Command from the Menu Bar
Click the Measure menu,
then Customize, and then
Measurement
Definitions to customize
the measurement setup
