99
Table 5-3. Replaceable Parts List (continued)
Ref. Desig Agilent Model Agilent Part Number Description
U115 all 1820-6045 IC SN75ALS61610
U116 all 1820-6170 IC SN75ALS6160
U117 all 1821-1740 IC 9914 talker/listener
VR2 all 1902-3172 diode, zener 11V
VR3,4 all 1902-0049 diode, zener 6.19V
VR6,7,8 all 1902-0766 diode, zener 18.2V
Y1,2 all 0410-2109 oscillator 12MHz
A8 Mechanical
all 1205-0564 heat sink (U33)
all 5001-6732 GPIB mounting plate
A9
6035A 5060-3401
Output Board
C1,2 6035A 0180-4231
cap 750
µF 350V
C3 6035A 0160-2569
cap 0.02
µF 2KV
CR1 6035A 1901-0325 diode 700V 35A
CR2,3 6035A 1901-0759 diode 600V 3A
R1-4 6035A 0764-0027 res 75K 5% 2W
Chassis Electrical
B1 all 3160-0097 fan
C6 6030A 0160-2569
cap 0.02
µF 20% 2KVdc (output board)
C2 6030A 0180-3703
cap 1500
µF 250V (output board)
6031A 0180-3493
cap 10000
µF 40V (output board)
6032A 0180-3491
cap 2600
µF 75V (output board)
CB1 all 3105-0126 circuit breaker 25A 250Vac
L4 all 5080-2307
choke (input line) 380
µH
S3 all 3101-0402 switch DPST (on/off)
W1 all 06032-60003 ribbon cable (A3 to A8)
W2 all 8120-4352 cable assembly, 3-pin (A1 to A8)
W3 all 06032-60002 cable assembly, 5-pin (A2 to A3)
W5,6 all 8120-4356 ribbon cable (A2 to A8)
Chassis Mechanical
all 06032-00025 chassis
all 5021-8403 front frame casting
all 5041-8802 top trim strip
all 5001-0539 side trim strip (2)
all 06032-00015 front sub-panel
6030A 06030-00012 front panel, screened
6031A 06031-00013 front panel, screened
6032A 06032-00023 front panel, screened
6035A 06035-00001 front panel, screened
all 01650-47401 knob, RPG adjust
all 2190-0736 spacer
all 5041-0309 plain key cap (4)
all 5041-2089 lettered key cap (LCL)
all 4040-1954 display window
all 06032-00011 fan baffle
all 06032-00012 dc output plate (lettered)
