Table 5-3. Replaceable Parts List (continued)
Ref. Desig Agilent Model Agilent Part Number Description
R68 all 0757-0400 res 90.9 1% 1/8W
R69 all 0698-6320 res 5K 0.1% 1/8W
R70 all 0757-0400 res 90.9 1% 1/8W
R71 all 0698-6320 res 5K 0.1% 1/8W
R72 all 0757-0400 res 90.9 1% 1/8W
R73 all 0757-0451 res 24.3K 1% 1/8W
R74 all 0757-0199 res 21.5K 1% 1/8W
R75 all 2100-3273 trimmer 2K 10%
R76 all 0698-3455 res 261K 1% 1/8W
R78 all 0698-3156 res 14.7K 1% 1/8W
R79,80 all 8159-0005 res 0 ohm
R82 all 0698-0082 res 464 1% 1/8W
R83-88 all 0698-3155 res 4.64K 1% 1/8W
R89 all 0757-0280 res 1K 1% 1/8W
R90,98,99 all 0698-3155 res 4.64K 1% 1/8W
R101 all 0698-6360 res 10K 0.1% 1/8W
R102 all 0698-3558 res 4.02K 1% 1/8W
R103 all 0698-3455 res 261K 1% 1/8W
R106 all 1810-0206 network, sip 10K X7
R109,110 all 0698-3155 res 4.64K 1% 1/8W
R111 all 0757-0316 res 42.2 1% 1/8W
R112 all 1810-0305 network, sip 4.7K X8
S1 all 3101-1973 GPIB switch
TBl all 0360-2312 terminal block 4-contact
U1 all 1826-0468 IC MC3423P1 0V-level detect
U2 all 5080-2157 IC GAL programmed
U4 all 1820-8773 IC 80C51 microprocessor
U5 all 1826-1369 IC LT1021 voltage regulator 10V
U6 all 5080-2624 IC EPROM AM27512
U7 all 1826-2187 IC converter PM-7545
U8 all 1818-4134 IC RAM MCM6164C55
U9 all 1826-2187 IC converter PM-7545
U11 all 1826-2187 IC converter PM-7545
U12 all 1820-3210 IC UART MC68B50P
U13 all 1990-0543 IC opto-isolator
U14 all 1821-1479 IC 80C196 microprocessor
U16 all 1820-2724 IC latch 74HC373
U19 all 1826-0161 IC LM324N quad op amp
U20 all 1826-0609 IC 8-input multiplexer
U24 all 1826-1475 IC LT1011 comparator
U25 all 1826-1896 IC LT1001 op amp
U28 all 1990-1387 IC opto-isolator
U31 all 1820-6789 IC 75176B RS485 driver
U32 all 1990-1387 IC opto-isolator
U33 all 1826-0536 IC LM340AK-5 voltage regulator 5V
U35 all 5080-2156 IC GAL programmed
U36 all 5080-2625 IC GAL programmed
U37 all 1820-4185 IC DS3658N interface
U64-69 all 1826-1896 IC LT1001 op amp
U70 all 1818-4932 IC EEPROM NMC9346
