Table 5-3. Replaceable Parts List
Ref. Desig Agilent Model Agilent Part Number Description
Al
6030A 06030-61032
Main Board Assembly
6031A 06031-61032 "
6032A 06032-61032 "
6035A 06030-61033 "
Cl,2,4,5,6,8 all 0180-4528
cap 1800
µF 200V
C9 all 0160-5932
cap 0.47
µF 250V
C10 6030A,35A 0180-3699
cap 470
µF 20% 35V
6031A,32A 0180-0426
cap 22
µF 250V
C11,12 6030A, 31A 0160-5895
cap 0.047
µF
6032A, 35A 0160-5933
cap 0.022
µF 10%
C13,14 6030A 0180-3702
cap 1600
µF 125V
6031A 0180-3425
cap 5500
µF 40V
6032A* 0180-3492
cap 2600
µF 75V
6035A 0180-4240
cap 900
µF 350V
C15,16 6030A,32A,35A 0180-3587
cap 1000
µF 50 V
6031A 0180-3425
cap 5500
µF 40V
C17,18 6030A,32A,35A 0180-0291
cap l
µF 35V
6031A 0180-3587
cap 1000
µF 50V
C19 6030A* 0160-0269
cap 0.047
µF 20%
6031A 0180-0291
cap 1
µF 35V
6032A* 0160-5286
cap 0.47
µF 20%
6035A* 0180-0904
cap 0.05
µF 1KV
C20 6030A,35A* 0160-6392
cap 0.047
µF 20%
6031A 0180-0291
cap 1
µF 35V
6032A* 0160-7732
cap 0.47
µF
C21 6030A,35A* 0160-6392
cap 0.047
µF
C22 6030A,35A* 0160-6392
cap 0.047
µF 20%
6031A* 0160-5377
cap 2.2
µF 10% 63V
6032A* 0160-7732
cap 0.47
µF
C23 6030A,35A* 0160-6392
cap 0.047
µF
6031A* 0160-7732
cap 0.47
µF
C24 6032A* 0160-4281 cap 2200pF 20%
C25 6030A* 0160-0269
cap 0.047
µF 20%
6031A* 0160-5377
cap 2.2
µF 10% 63V
6032A* 0160-5286
cap 0.47
µF 20%
6035A* 0180-0904
cap 0.05
µF 1KV
C26 6031A* 0160-5377
cap 2.2
µF 10% 63V
6032A* 0160-4281 cap 2200pF 20%
C27 All 0160-6805
cap 0.01
µF 400V
C27 6031A* 0160-4281 cap 2200pF 20%
C28 6031A* 0160-7732
cap 0.47
µF
C29 6030A,32A,35A 0160-4323
cap 0.047
µF 20%, 250V
6031A* 0160-4281 cap 2200pF 20%
C30 6030A,32A,35A 0160-7606
cap 1
µF 20%
C32 6031A 0160-4323
cap 0.047
µF 20%, 250V
C33 6031A 0160-7606
cap l
µF 20%
C34 All 0160-6805
cap 0.01
µF 400V
* Part of output filter, mounted on output bus bars.
