Agilent Technologies 6030A User Manual

82
Table 5-3. Replaceable Parts List (continued)
Ref. Desig Agilent Model Agilent Part Number Description
CR1 all 1901-0731 power rectifier 400V
CR2 all 1901-0731 power rectifier 400V lA
CR3,4 all 1901-0050 diode, switching 80V 200mA
CR5-13 all 1901-0731 power rectifier 400V
DS1 all 1990-0517 LED, visible
F1 all 2110-0001 fuse lAM, 250V
F2 all 2110-0671 fuse 250mAM, 125V
J2 all 1251-5384 connector, 3-pin
J5 all 5060-2877 ribbon cable (W8)
J6 all 5060-2878 ribbon cable (W7)
J7,8 all 1251-0600 connector, single contact
J9,10 all 1251-5613 connector, single contact
L,N,P all 1251-5613 connector, single contact
J11-14 all 1251-0600 connector, single contact
K1, K2 all 0490-1834 relay 1C 15Vdc-coil 30A 30Vdc
L1 all 9170-0707 ferrite core (jumper 06012-80003)
L2 6030A,32A,35A 9170-1267 magnetic core (jumper 5080-2040)
6031A 06011-80092 output choke
L3 6030A 9140-1064 output choke
6031A 06011-80092 output choke
6032A 06012-80095 output choke (core 9170-0721)
6035A 5080-2131
output choke 18
µH 5A
L4 6031A 9170-1267 magnetic core (jumper 5080-2040)
Q1 6030A,31A,32A 1855-0456 MOSFET N-chan
6035A 1855-0456 MOSFET N-chan
Q2 all 1855-0665 MOSFET N-chan
R1-4 all 0811-1866 res 10K 1% 5W
R5 all 0757-0418 res 619 1% 1/8W
R7 all 0698-5525 res 6.8 5% 1/2W
R8 all 0757-0765 res 36.5K 1% 1/8W
R9 all 0811-3700 res 20 10% 20W
R10 all 0811-3699 res 6 10% 20W
R11 6030A,35A 5080-2079 current sensing resistor
6032A 06032-80001 current sensing resistor
R12 6030A,31A,32A 0699-0188 res 2.2 5% 1/4W
6035A 0698-3492 res 26.1 ohms
R13 6030A,32A 0699-0188 res 2.2 5% 1/4W
6031A 06011-80001 current sensing resistor
6035A 0698-3492 res 26.1 ohms
R14,15 6031A 7175-0057 solid tinned copper wire
6032A 0812-0100 res 2K 5% 5W
R16,17 all 0683-1065 res 10M 5% 1/4W
R18 all 0757-0921 res 750 1% 1/8W
R19 all 0757-0403 res 121 1% 1/8W
R20* 6031A 0699-0208 res 1 5% 1/4W
R21-22* 6032A 0699-0208 res 1 5% 1/4W
R23* 6031A 0699-0208 res 1 5% 1/4W
R24 all 0686-2015 res 200 5% 1/2W
R25 6031A,32A 0811-1869 res 30 3W
* Part of output filter, mounted on output bus bars.
