83
Table 5-3. Replaceable Parts List (continued)
Ref. Desig Agilent Model Agilent Part Number Description
R29,30 6030A 0811-1887 res 0.05 5% 10W
6035A 0811-3557 res 0.5 5% 10W
R31 6030A 0757-0367 res 100K 1% 1/2W
6035A 0698-8959 res 619K 1% 1/8W
R32 6030A 0686-7535 res 75K 5% 1/2W
6035A 0698-8959 res 619K 1% 1/8W
R33 6030A 0757-0451 res 24.3K 1% 1/8W
6035A 0757-0471 res 182K 1% 1/8W
R34 6030A,35A 0757-0438 res 5.11K 1% 1/8W
R35 6030A,35A 0698-8827 res 1M 1% 1/8W
R36,37 6030A 0811-1909 res 500 5% 10W
6035A 0811-1913 res 1.5K 5% 10W
R38,39 6030A,35A 0757-0467 res 121K 1% 1/8W
R41 6030A,35A 0764-0041 res 30 5% 2W
R43,44 all 0698-0085 res 2.61k 1% 1/8W
R45 all 0698-8827 res 1M 1% 1/8W
R46 all 0757-0419 res 681 1% 1/8W
R47, 48 all 0698-3622 res 120 5% 2W
R49 all 0757-0401 res 100 1% 1/8W
S1 all 3101-2046 switch, DPDT slide
S2 all 3101-1914 switch, 2-DPDT slide
T1 all 9100-4350 current transformer
T2 6030A 06030-80090 power transformer
6031A 06011-80090 power transformer
6032A 06032-80090 power transformer
6035A 9100-4827 power transformer
T3 all 9100-4864 bias transformer
U1 all 1906-0389 rectifier bridge
U3 all 1826-0393 IC, voltage regulator 1.2/37V
U5 all 1826-0643 IC, voltage regulator 3/30V
U6 all 1990-1074 IC, opto-isolator
VR1 all 1902-0955 diode, zener, 7.5V
XA4,5 6030A,35A 1252-1052 connector 64-pin
6031A,32A 1251-7891 connector 64-pin
6030A 5060-3520 Output filter board
6031A 5060-3524 Output filter board
6032A 5060-3523 Output filter board
6035A 5060-3521 Output filter board
A1 Mechanical
all 1205-0282 heatsink (U3)
all 1205-0862 heatsink (U1)
all 2110-0726 fuse clips (F1)
all 0403-0086 bumper foot (R9,10)
all 0380-1692 standoff, 109mm (4)
