Table 5-3. Replaceable Parts List (continued)
Ref. Desig Agilent Model Agilent Part Number Description
A2
6030A 06030-60022
Control Board Assembly
6031A 06011-60022 "
6032A 06032-60022 "
6035A 06030-60028 "
C1-4 all 0160-5422
cap 0.047
µF 20% 50V
C5 all 0160-4801 cap 100pF 5% 100V
C6-7 all 0160-5422
cap 0.047
µF 20% 50V
C8 all 0160-5892
cap 0.22
µF 10%
C9 all 0160-5422 cap 0.047 20% 50V
C10 all 0160-4807 cap 33pF 5% 100V
C11 all 0160-5892
cap 0.22
µF 10%
C12 all 0160-4830 cap 2200pF 10% 100V
C13-16 all 0160-5422
cap 0.047
µF 20% 50V
C17 6030A,32A,35A 0160-4833
cap 0.022
µF 10% 100V
6031A 0160-4832
cap 0.01
µF 10% 100V
C18 all 0160-5892
cap 0.22
µF 10%
C19 6030A,31A,32A 0160-5469
cap 1
µF 10% 50V
6035A 0160-5534
cap 0.1
µF 10% 63V
C20 6030A,32A,35A 0160-5892
cap 0.22
µF 10%
6031A 0160-5534
cap 0.1
µF 10% 63V
C21,22 all 0160-5422
cap 0.047
µF 20% 50V
C24 6030A,32A,35A 0160-0162
cap 0.022
µF 10% 200V
6031A 0160-0161
cap 0.01
µF 10% 200V
C25 6030A,32A,35A 0160-4812 cap 220pF 5% 100V
C26 all 0160-4807 cap 33pF 5% 100V
C27 6030A,32A,35A 0160-5892
cap 0.22
µF 10%
6031A 0160-5534
cap 0.1
µF 10% 63V
C28 6030A,32A,35A 0160-4834
cap 0.047
µF 10% 100V
6031A 0160-4833
cap 0.022
µF 10% 100V
C29 all 0160-5422
cap 0.047
µF 20% 50V
C30 all 0160-4807 cap 33pF 5% 100V
C31 all 0160-5422
cap 0.047
µF 20% 50V
C32 6030A,32A,35A 0160-5644
cap 0.033
µF 10% 50V
6031A 0160-4832
cap 0.01
µF 10% 100V
C33 6030A 0160-4822 cap 1000pF 5% 100V
6032A 0160-4831 cap 4700pF 10% 100V
6035A 0160-4824 cap 680pF 5% 100V
C34 6031A 0160-4832
cap 0.01
µF 10% 100V
6032A 0160-4835
cap 0.1
µF 10% 50V
C35 all 0160-5422
cap 0.047
µF 20% 50V
C36 all 0160-4812 cap 220pF 5% 100V
C37 6032A 0160-4830 cap 2200pF 10% 100V
C38-40 all 0160-5422
cap 0.047
µF 20% 50V
C41 all 0160-4831 cap 4700pF 10% 100V
C42 all 0160-4812 cap 220pF 5% 100V
C43 all 0160-4831 cap 4700pF 10% 100V
C44 all 0160-5422
cap 0.047
µ F 20% 50V
C45 all 0160-4812 cap 220pF 5% 100V
C46 6030A,31A,32A 0160-5166
cap 0.015
µF 20% 100V
6035A 0160-4832
cap 0.01
µF 20% 100V
