Agilent Technologies 6030A User Manual

85
Table 5-3. Replaceable Parts List (continued)
Ref. Desig Agilent Model Agilent Part Number Description
C47 all 0160-5422
cap 0.047
µF 20% 50V
C48,49 all 0160-4835
cap 0.1
µF 10% 50V
C50 all 0180-0291
cap 1
µF 10% 35V
C51 all 0180-1731
cap 4.7
µF 50V
C52 all 0180-0230
cap 1
µF 20% 50V
C53 all 0180-1731
cap 4.7
µF 50V
C54 all 0180-0291
cap 1
µF 10% 35V
C55 all 0180-0230
cap 1
µF 20% 50V
C56,57 all 0160-5422
cap 0.047
µF 20% 50V
C58 all 0160-4801 cap 100pF 5% 100V
C59 all 0160-4835
cap 0.1
µF 10% 50V
C60 all 0160-5422
cap 0.047
µF 20% 50V
C61 all 0160-4812 cap 220pF 5% 100V
C62 all 0160-1835
cap 0.1
µF 10% 50V
C63 all 0180-1980
cap 1
µF 5% 35V
C64 all 0180-0116
cap 6.8
µ F 10% 35V
C65 all 0160-5422
cap 0.047
µF 20% 50V
C66 all 0160-4801 cap 100pF 5% 100V
C67 all 0160-5422
cap 0.047
µF 20% 50V
C68 all 0160-1822 cap 1000pF 5% 100V
C69,70 all 0160-5422
cap 0.047
µ F 20% 50V
C71 all 0180-0376
cap 0.47
µF 10% 35V
C72 all 0180-2624
cap 2000
µF 10V
C73 all 0180-3407
cap 2200
µF 35V
C74,75 all 0160-5098
cap 0.22
µF 10% 50V
C76 all 0160-4835
cap 0.1
µF 10% 50V
C77 all 0160-4833
cap 0.022
µF 10% 100V
C78 all 0160-4832
cap 0.01
µF 10% 100V
C79 all 0160-4830 cap 2200pF 10% 100V
C80 all 0160-4813 cap 180pF 5% 100V
C81 all 0160-5422
cap 0.047
µF 20% 50V
C82 all 0160-4812 cap 220pF 5% 100V
C83 all 0160-5422
cap 0.047
µF 20% 50V
C84 all 0160-4812 cap 220pF 5% 100V
C85 all 0160-4832
cap 0.01
µF 10% 100V
CR1-6 all 1901-0033 gen prp 180V 200mA
CR7,8 all 1901-0050 switching 80V 200mA
CR9,10 all 1901-0033 gen prp 180V 200mA
CR11 all 1901-0050 switching 80V 200mA
CR12 all 1901-0033 gen prp 180V 200mA
CR13,14 all 1901-0050 switching 80V 200mA
CR15,16 all 1901-0033 gen prp 180V 200mA
CR17,18 all 1901-0050 switching 80V 200mA
CR19 all 1901-0033 gen prp 180V 200mA
CR20-31 all 1901-0050 switching 80V 200mA
CR32 all 1901-0992 schottky 40V 3A
J1,2 all 1251-8417 connector 16-pin
J3 6030A,35A 1251-7743 connector 26-pin
6031A,32A 1251-5927 connector 26-pin
J4 all 1251-8676 connector 5-pin
