86
Table 5-3. Replaceable Parts List (continued)
Ref. Desig Agilent Model Agilent Part Number Description
J5,6 all 1251-5240 connector 20-pin
J15 6030A,35A 1251-0600 connector 1-pin
L1 all 06023-80090 choke
Q1-3 all 1854-0823 transistor NPN Si
Q4-6 all 1855-0413 J-FET P-chan Si
Q7 all 1854-0823 transistor NPN Si
Q8 all 1853-0012 transistor PNP Si
Q9 all 1854-0635 transistor NPN Si
Q10 all 1853-0036 transistor PNP Si
Q11 all 1858-0023 transistor array
R1,2 all 0686-5125 res 5.1K 5% 1/2W
R3 all 0683-5125 res 5.1K 5% 1/4W
R4 all 0757-0483 res 562K 1% 1/8W
R5 all 0683-2015 res 200 5% 1/4W
R6 6030A 0698-6615 res 3.75K 0.1%
6031A 0699-1011 res 3.32K 1% 1/8W
6032A 0698-7631 res 2.87K 1%
6035A 0757-0424 res 1.1K 1% 1/8W
R7 all 0683-5125 res 5.1K 5% 1/4W
R8 all 2100-3353 trimmer 20K 10%
R9 6030A,31A,32A 2100-3352 trimmer lK 10%
6035A 2100-3351 trimmer 500 10%
R10 all 0698-3433 res 28.7 1% 1/8W
R11,12 6030A,32A,35A 0757-0465 res 100K 1% 1/8W
R13 6030A,35A 0698-3430 res 21.5 1% 1/8W
6032A 0757-0379 res 12.1 1% 1/8W
R14,15 all 0686-5125 res 5.1K 1/2W
R16 all 0683-2015 res 200 5% 1/4W
R17 all 0698-7082 res 100K 1% 1/8W
R18 all 0683-1025 res 1K 5% 1/4W
R19 all 0757-0442 res 10K 1% 1/8W
R20 6030A,35A 0686-5135 res 51K 5% 1/2W
6031A,32A 0686-1025 res 1K 5% 1/4W
R21 6030A,35A 2100-3274 trimmer 10K 10%
6031A 2100-3350 trimmer 200 10%
6032A 2100-3273 trimmer 2K 10%
R22 all 2100-3353 trimmer 20K 10%
R23 all 2100-3273 trimmer 2K 10%
R24 all 2100-3350 trimmer 200 10%
R25 all 2100-3273 trimmer 2K 10%
R26 all 2100-3274 trimmer 10K 10%
R27 all 0757-0470 res 162K 1% 1/8W
R28 all 0757-0464 res 90.9K 1% 1/8W
R29 all 0698-4509 res 80.6K 1% 1/8W
R30 all 0757-0280 res 1K 1% 1/8W
R31 6030A,31A,32A 0698-3260 res 464K 1% 1/8W
6035A 0757-0741 res 182K 1% 1/8W
R32 all 0698-8827 res 1M 1% 1/8W
R33 all 0698-3449 res 28.7K 1% 1/8W
R34 6030A,32A,35A 0757-0458 res 51.1K 1% 1/8W
