Table 5-3. Replaceable Parts List (continued)
Ref. Desig Agilent Model Agilent Part Number Description
U1-4, 6-11 all 1820-1433 IC shift register, 8-bit
U5 all 1820-1216 IC decoder, 3-to-8 line
U12 all 1820-1216 IC decoder, 3-to-8 line
U13 all 1820-1112 IC flip flop, D-type
U14 all 1820-1199 IC inverter, HEX
U15 all 1820-1197 IC gate quad NAND
U16 all 1820-1433 IC shift register, 8-bit
U17 all 1820-1975 IC shift register, 8-bit
A3 Mechanical
all 4040-1615 stand off (DS1-15)
A4
all 06011-60023
FET Board
C1 all 0160-4569
cap 0.01
µF 10% 800Vdc
C2 all 0160-5981
cap 0.047
µF 10% 630Vdc
C3 all 0160-4569
cap 0.01
µF 10% 800Vdc
C4 all 0160-5981
cap 0.047
µF 10% 630Vdc
C5,6 all 0160-4835
cap 0.1
µF 10% 50V
C7 all 0180-0116
cap 6.8
µF 10% 35V
C8 all 0180-0228
cap 22
µF 10% 15V
CR1 all 1901-1418 power rectifier 600V
CR2,3 all 1901-1087 power rectifier 600V
CR4 all 1901-1418 power rectifier 600V
CR5-11 all 1901-0050 diode, switching 80V 200mA
F1,2 all 2110-0671 fuse 125mAM, 125V
L14 all 9100-1610
coil 0.15
µH 20%
P1 all 1252-1053 connector 64-pin
Q1-4 all 1855-0473 FET N-channel
Q5,6 all 1854-0585 transistor NPN Si
R1-4 all 0811-1065 res 150 5% 10W
R5-8 all 0698-3609 res 22 5% 2W
R9-11 all 0698-5139 res 3.9 5% 5W
R12 all 0757-0466 res 110K 1% 1/8W
R13-16 all 0698-3609 res 22 5% 2W
R17-19 all 0698-5139 res 3.9 5% 0.5W
R20 all 0757-0379 res 12.1 1% 1/8W
R21 all 0683-1505 res 15 5% 1/4W
R22 all 0683-1815 res 180 5% 1/4W
R23,24 all 0686-2005 res 20 5% 1/2W
R25 all 0757-0466 res 110K 1% 1/8W
R26 all 0683-1815 res 180 5% 1/4W
R27 all 0757-0379 res 12.1 1% 1/8W
R28 all 0683-1505 res 15 5% 1/4 W
R29-33 all 0683-0475 res 4.7 5% 1/4W
R34 all 0683-0275 res 2.7 5% 1/4W
TS1 all 3103-0081 switch, thermal +202F
T1 all 06011-80091 transformer
T2 all 06011-80095 transformer
U1-3 all 1820-1050 IC driver dual NOR
VR1,2 all 1902-0779 diode, zener 11.8V 5%
