93
Table 5-3. Replaceable Parts List (continued)
Ref. Desig Agilent Model Agilent Part Number Description
A4 Mechanical
all 1205-0398 heatsink (CR1,4)
all 1252-0093 socket pin (Q1-4) (8)
all 06032-20001 heatsink (Q1,Q2)
all 06032-20002 heatsink (Q3,Q4)
all 0380-1524 standoff, hex (7)
A5
6030A 06030-60024
Diode Board
6031A 06011-60024 "
6032A 06032-60029 "
6035A 06030-60029 "
C1 6030A,32A,35A 0180-3167
cap 1000
µF 20% 25V
6031A 0160-4832
cap 0.01
µF 10% 100V
C2 6030A 0160-5464
cap 0.01
µF 5% 1.5KVdc
6031A 0160-5422
cap 0.047
µF 20% 50V
6032A 0160-4569
cap 0.01
µF 10% 800Vdc
6035A 0160-7222
cap 0.0022
µF 10% 1600Vdc
C3 6030A,32A,35A 0160-5422
cap 0.047
µF 20% 50Vdc
6031A 0180-3167
cap 1000
µF 25V
C4 6030A,32A 0160-4832
cap 0.01
µF 10% 100Vdc
6031A 0160-6077
cap 0.015
µF 200V
6035A 0160-4835
cap 0.1
µF 10% 50V
C5 6030A 0160-5464
cap 0.01
µF 5% 1.5KVdc
6031A 0160-6077
cap 0.015
µF 200V
6035A 0160-7222
cap 0.0022
µF 10% 1600Vdc
C7 6035A 0160-5166
cap 0.015
µF 10% 100Vdc
CR1 6030A,32A,35A 1901-0050 diode, switching 80V 200ma
6031A 1901-1127 power rectifier 150V 70A
CR2 6030A,32A,35A 1901-0731 power rectifier 400V lA
6031A 1901-0050 diode, switching 80V 200ma
CR3 all 1901-0050 diode, switching 80V 200mA
CR4 6030A 1901-1542 power rectifier 400V 50A
6031A 1901-0731 power rectifier 400V lA
6032A 1901-0887 power rectifier 300V 50A
6035A 1901-1388 power rectifier lKV 40A
CR5 6030A 1901-1542 power rectifier 400V 50A
6031A 1901-1127 power rectifier 150V 70A
6035A 1901-1388 power rectifier lKV 40A
CR6 6030A,35A 1902-3203 diode, zener 14.7V 5%
F1 6031A,32A 2110-0546 fuse 5AM, 125V
L1 6030A 9170-1334 ferrite core (jumper 5080-2065)
6031A 06011-80003 ferrite core (jumper 8150-4777)
6032A 9170-0707 ferrite core (jumper 06012-80003)
6035A 5080-2132 inductor L2
L2 6030A 9170-1334 ferrite core (jumper 5080-2065)
6031A 06011-80003 ferrite core (jumper 8150-4777)
6035A 5080-2132 inductor
L3 6030A, 35A 9170-0894 core shield bead (ref Q1)
P1 all 1252-1053 connector 64-pin
