General Information
21
Table 1-2a. Performance Specifications for Series 657xA
1
Parameter
Agilent
6571A
Agilent 6572A Agilent 6573A Agilent 6574A
Agilent
6575A
Specifications are warranted over the temperature range 0 to 55° C with a resistive load and the output connected for local
sensing.
Output Ratings
Voltage:
0 - 8 V 0 - 20 V 0- 35 V 0 - 60 V 0 - 120 V
Current:
0 - 220 A 0 - 100 A 0 - 60 A 0 - 35 A 0 - 18 A
Front Panel Programming Accuracy (@ 25° C ± 5 °C)
Voltage:
0.04% +8 mV 0.04% +20 mV 0.04% +35 mV 0.04% +60 mV 0.04% +120 mV
Current:
0.l1 % +125 mA 0.l1 % +60 mA 0.l1 % +40 mA 0.l1 % +25 mA 0.l1 % +12 mA
Ripple & Noise (from 20 Hz to 20 MHz with outputs ungrounded, or with either output terminal grounded)
Constant Voltage(rms):
650 µV 750 µV 800 µV
1.25 mV 1.9 mV
Constant Voltage (p-p):
7 mV 9 mV 9 mV 11 mV 16 mV
Constant Current (rms):
200 mA 100 mA 40 mA 25 mA 12 mA
Readback Accuracy (with respect to actual output @ 25° C ± 5 °C)
Voltage:
0.05% +12 mV 0.05% +30 mV 0.05% +50 mV 0.05% +90 mV 0.05% +180 mV
Current
0.1% +150 mA 0.1% +100 mA 0.1% +60 mA 0.1% +35 mA 0.1% +18 mA
Load Regulation (change in output voltage or current for any load change within ratings)
Voltage:
0.002%+300µV 0.002%+650µV
0.002%+1.2mV 0.002%+2mV 0.002%+4mV
Current:
0.005%+10 mA 0.005%+7 mA 0.005%+4 mA 0.005%+2 mA 0.005%+1 mA
Line Regulation (change in output voltage or current for any line change within ratings
Voltage:
0.002%+300µV 0.002%+650µV
0.002%+1.2mV 0.002%+2mV 0.002%+4mV
Current:
0.005%+10 mA 0.005%+7 mA 0.005%+4 mA 0.005%+2 mA 0.005%+1 mA
Transient Response Time
< 900 µS for the output voltage to recover to within 100 mV following any step
change in load current from 100% to 50%, or 50% to 100% of the rated current.
AC Input Ratings (selectable via internal switching - see Appendix B)
Nominal line voltage
200 Vac:
174-220 Vac
(Below 185 Vac, derate
output voltage linearly to:) 7.8 V 18.0 V 31.5 V 56.5 V 108 V
230 Vac:
Frequency range:
191-250 Vac
47-63 Hz
Output Terminal Isolation
±240 Vdc (maximum, from output signal ground)
Note 1: For Supplemental Characteristics, see Table 1-2b.
