Agilent Technologies 6571A Service Manual

Replaceable Parts 87
Table 5-3. Main Chassis, Replaceable Parts
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
A1 5060-3400 Front Panel Board, for all 667xA Models (see Table
5-4 )
A1 -- Front Panel Board Tested & Initialized (see Table
5-4)
6571A 06571-61001
6572A 06572-61001
6573A 06573-61001
6574A 06574-61001
6575A 06575-61001
A2 5060-3398 Isolator Board (see Table 5-5)
A2 5060-3592 GPIB Board (see Table 5-6)
A3 5060-3338 FET Board Heat Sink Assembly (see Table 5-7)
A4 5060-3341 AC Input Board (see Table 5-8)
A5 -- Control Board (see Table 5-9)
6571A, 6671A 06671-61020
6572A, 6672A 06672-61020
6573A, 6673A 06673-61020
6574A, 6674A 06674-61020
6575A, 6675A 06675-61020
A6 -- Output Filter Board (see Table 5-10)
6571A, 6671A 06671-61024
6572A, 6672A 06672-61024
6573A, 6673A 06673-61024
6574A, 6674A 06674-61024
6575A, 6675A 06675-61024
A7 -- Snubber Board (see Table 5-11)
6571A, 6671A 06671-61021
6572A, 6672A 06672-61021
6573A, 6673A 06673-61021
6574A, 6674A 06674-61021
6575A, 6675A 06675-61021
B1 5060-3436 Fan assembly
C416-419 0180-4369
Capacitor 1500μF 400V
D900 -- Diode rectifier
6571A, 6671A 1906-0396
6572A, 6672A 1906-0397
6573A, 6673A 1906-0398
6574A, 6674A 1906-0398
6575A, 6675A 1906-0404
FL1 9135-0439 Filter RFI
J900 1251-8667 Connector post test point
L900 Choke output (Model specific)
6571A, 6671A 06671-80003
6572A, 6672A 06672-80003
6573A, 6673A 06673-80003
6574A, 6674A 06674-80002
6575A, 6675A 06675-80003
