88 Replaceable Parts
Table 5-3. Main Chassis, Replaceable Parts (continued)
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS (continued)
T900 -- Transformer power output (Model specific)
6571A, 6671A 9100-4909
6572A 6672A 9100-4946
6573A, 6673A 9100-4945
6574A 6674A 9100-4910
6575A, 6675A 9100-4944
CABLES (see Figure 6-2)
W1 5080-2172 Cable assy 4-wire (AlS1 to A4 AC Input bd)
W2 8120-4944 Cable ribbon (front panel display AlDSP1)
W3 5080-2166 Cable ribbon (A4 AC Input bd to A5 Control bd)
W4 5080-2167 Cable phone (A2 GPIB bd to A5 Control bd)
W5 5080-2168 Cable phone (A2 GPIB bd to A1 Front Panel bd)
W6 5080-2169 Cable assy 2-wire (A2 GPIB bd to A4 AC Input bd)
W7 5080-2170 Cable assy 2-wire (A3 FET bd to A5 Control bd)
W8 5080-2171 Cable assy 2-wire (A3 FET bd to A4J400 on A4 AC
Input bd)
W9 5080-2178
Cable assy 2-wire (A3 FET bd to ± rails on A4 AC
Input bd)
CHASSIS MECHANICAL
G1,G2 0960-0912 Optical Encoders (Voltage and Current Controls)
DSP1 5063-2304 LCD Display
Keypad 5040- 1665 Keypad
S1 3101-3088 AC ON/OFF line switch
-- 5040-1675 Bezel output
-- 1510-0107 Binding post (rear panel gnd post)
-- 5001-6740 Bracket GPIB
-- 5040-1673 Bracket polycarb
-- 5001-6766 Bracket A7 Snubber bd
-- 5000-6554 Bracket strap
-- 5041-8801 Bumper foot
-- -- Bus bar heat sink (Model specific)
6571A, 6671A 06671-00007
6572A, 6672A 06671-00007
6573A-6575A 5001-6749
6673A-6675A 5001-6749
-- -- Bus bar, minus (Model specific)
6571A, 6671A 06671-00008
6572A, 6672A 06671-00008
6573A, 6673A 5001-6750
6574A, 6674A 5001-6750
6575A, 6675A 5001-6750
