Replaceable Parts 105
Table 5-9. A5 Control Board Replaceable Parts (continued)
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
R685 (Model specific)
6571A-6574A,
6671A-6674A
6575A, 6675A
0757-0410
0757-0413
Resistor 301 Ω 1% 0.125W
Resistor 392 Ω 1% 0.125W
R687 (Model specific)
6571A-6574A,
6671A-6674A
0757-0434 Resistor 3.65K 1%
6575A, 6675A 0757-0443 Resistor 11K 1%
R688 0757-0429 Resistor 1.82K 1%
R689 (Model specific)
6571A, 6671A 0757-0472 Resistor 200K 1%
6572A, 6672A 0698-3450 Resistor 42.2K 1%
6573A, 6673A 0698-3260 Resistor 464K 1%
6574A, 6674A 0698-8827 Resistor 1 M 1% 0.125W
6575A, 6675A 0757-0472 Resistor 200K 1%
R690 (Model specific)
6571A, 6671A 0757-0453 Resistor 30.1K 1%
6572A, 6672A 0698-1254 Resistor 536K 1%
6573A, 6673A 0757-0480 Resistor 432K 1%
6574A, 6674A 0699-1254 Resistor 536K 1% 0.125W
6575A, 6675A 0699-0070 Resistor 3.16 M 1%
R691 (Model specific)
6571A, 6671A 0757-0442 Resistor 10K 1% 0.125W
6572A, 6672A 0757-0451 Resistor 24.4K 1%
6573A, 6673A 0698-3450 Resistor 42.2K 1%
6574A, 6674A 0757-0462 Resistor 75K 1% 0.125W
6575A, 6675A 0698-3460 Resistor 422K 1%
R692 (Model specific)
6571A, 6671A,
6572A, 6672A
0698-8827 Resistor 1M 1% 0.125W
6573A, 6673A,
6574A, 6674A
0699-0070 Resistor 3.16M 1%
6575A, 6675A (Not used)
R693 (Model specific)
6571A-6574A,
6671A-6674A
0698-3558 Resistor 4.02K 1% 0.125W
6575A, 6675A 0757-0442 Resistor 10K 1%
R694 0699-0070 Resistor 3.16 M 1%
R696 (Model specific)
6571A-6574A,
6671A-6674A
0757-0468 Resistor 130K 1% 0.125W
6575A, 6675A 0698-4536 Resistor 340K 1%
R697 (Model specific)
6571A, 6671A 8159-0005
Resistor 0 Ω
6572A, 6672A 0698-8827 Resistor 1 M 1% 0.125W
6573A, 6673A 8159-0005
Resistor 0 Ω
6574A, 6674A 0699-0070 Resistor 3.16 M 1%
6575A, 6675A (Not used)
