Agilent Technologies 6674A

114 Replaceable Parts
Table 5-10. A6 output Filter Board Replaceable Parts (continued)
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
R937 (Model specific)
6571A, 6671A (Not used)
6572A, 6672A
6573A, 6673A
0698-4416
Resistor 169 Ω 1% 0.125W
6574A, 6674A 0757-0274 Resistor 1.21K 1%
6575A, 6675A 0698-4416
Resistor 169 Ω 1% 0 125W
R938 (Model specific)
6571A, 6671A 8159-0005
Resistor 0 Ω
6572A-6575A,
6672A-6675A
(Not used)
T900 (Model specific) See Main Chassis, Electrical Parts
6571A, 6671A 9100-4909 Transformer power
6572A, 6672A 9100-4946 Transformer power
6573A, 6673A 9100-4945 Transformer power
6574A, 6674A 9100-4910 Transformer power
6575A, 6675A 9100-4944 Transformer power
U901 (Model specific)
6571A, 6671A (Not used)
6572A-6575A,
6672A-6675A
1826-0890 IC LN358A
VR901 1902-0960 Diode zener 12V 5%
VR902 (Model specific)
6571A, 6671A (Not used)
6572A, 6672A 1902-0960 Diode zener 12V 5%
6573A-6575A,
6673A-6675A
(Not used)
W900,901 1251-4180
Connector (R902, ± ISEN)
W910,911 (Model specific)
6571A, 6671A,
6572A, 6672A
(Not used)
6573A, 6673A 5080-2177
6574A, 6575A,
6674A, 6675A
(Not used)
W912,913 (Model specific)
6571A-6574A,
6671A-6674A
(Not used)
6575A, 6675A 5080-2177
W914 (Model specific)
6571A, 6671A,
6572A, 6672A
(Not used)
6573A, 6673A 5080-2177
6574A, 6575A,
6674A, 6675A
(Not used)
